| HDCP |
HDCP 1.4 (HDMI / DisplayPort) |
| Tilt |
-5/30 degree |
| sRGB |
Yes |
| Pivot |
-/+90 degree |
| Swivel |
-/+180 degree |
| EyeSafe |
Yes |
| On mode |
12.14 W (typ.) (EnergyStar test method) |
| USB Hub |
USB3.2, Gen1, 5G, Upstream: 1x USB-B Downstream: USB-A x4 (with x1 fast charge B.C 1.2) |
| Altitude |
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
| ECO mode |
7.7 W (typ.) |
| EasyRead |
Yes |
| Off mode |
0.3W (typ) |
| SoftBlue |
Yes |
| Brightness |
300 cd/m² |
| Panel Size |
23.8 inch / 60.47 cm |
| Sync Input |
Separate Sync, Sync on Green |
| Pixel pitch |
0.2745(H)mm x 0.2745(V)mm |
| Aspect ratio |
16:09 |
| Flicker-free |
Yes |
| Power supply |
Built-in, 100-240VAC, 50-60Hz |
| Signal Input |
VGA x1, HDMI 1.4 x 1, DisplayPort 1.2 x 1 |
| Standby mode |
0.3W (typ) |
| Adaptive sync |
Yes |
| OSD Languages |
Brazil Portuguese, Czech, Dutch, English, French, Finnish, German, Greek, Hungarian, Italian, Japanese, Korean, Portuguese, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian |
| Pixel Density |
93 PPI |
| SmartContrast |
50,000,000:1 |
| Viewing angle |
178º (H) / 178º (V) @ C/R > 10 |
| Audio (In/Out) |
Audio out, Audio-in |
| Backlight type |
W-LED system |
| Display colors |
16.7M (8 bit) |
| LCD panel type |
IPS technology |
| Control software |
SmartControl* |
| User convenience |
SmartImage, Input, Brightness, Menu, Power On/Off |
| Built-in Speakers |
2Wx2 |
| Height adjustment |
150 mm |
| Other convenience |
Kensington lock, VESA mount (100x100mm) |
| Relative humidity |
20%-80 % |
| Maximum resolution |
1920x1080@75Hz (VGA), 1920x1080@120Hz (HDMI/DP) |
| Scanning Frequency |
VGA: 30 KHz - 85 KHz (H) / 48 Hz - 75 Hz; HDMI/DP: 30k - 140 kHz (H) / 48 Hz - 120 Hz (V) |
| MTBF (demonstrated) |
70,000 hrs (excluded backlight) |
| Picture enhancement |
SmartImage |
| Power LED indicator |
Operation - White, Standby mode- White (blinking) |
| Color gamut (typical) |
sRGB: 110%, NTSC: 96%* |
| Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
| Effective viewing area |
527.04(H)x296.46(V) mm |
| Packaging in mm (WxHxD) |
615 x 385 x139 mm |
| Product with stand (kg) |
5.57 kg |
| Response time (typical) |
4 ms (Gray to Gray)* |
| Contrast ratio (typical) |
1500:01:00 |
| Plug & Play Compatibility |
DDC/CI, Mac OS, sRGB, Windows 11 / 10 |
| Product without stand (kg) |
3.55 kg |
| Product without stand (mm) |
542 x 320 x 85 mm |
| Product with packaging (kg) |
7.58 kg |
| Temperature range (storage) |
-20°C to 60 °C |
| Temperature range (operation) |
0°C to 40 °C |
| Product with stand(max height) |
542 x 499 x 228 mm |
